| Quantity: | |
|---|---|
Metal
TOYOE
| The base of this product adopts a honeycomb reinforcing rib layout—a design inspired by the honeycomb’s natural structural efficiency. This layout distributes stress evenly across the base, enhancing overall stability and load-bearing capacity without adding excessive weight, laying a solid, lightweight foundation for the product’s performance |
To further optimize the base, topological optimization algorithms are applied: key load-bearing areas, which bear the brunt of pressure during use, are thickened to 4.2mm to ensure sufficient strength; meanwhile, non-load-bearing areas are thinned to 1.8mm to reduce unnecessary material consumption. This targeted adjustment maximizes material utilization, balancing structural robustness with cost and weight efficiency
 |  |  |
| According to finite element analysis, in the 1.2-meter drop test, stress is maximally concentrated at the reinforcing rib intersections, which is significantly lower than the material’s yield strength. |
An auto parts enterprise’s real-world testing demonstrates: this pallet handles 5 tons of static load and 4-layer dynamic stacking without deformation, boasting 40% greater load-bearing efficiency than conventional plastic pallets. |
|
| Innovative self-locking sleeve connection: lateral shear strength up to 15kN, and remains intact in 3Hz-50Hz frequency band after vibration table tests. |
